QC75 Series QC7556 Pocket 2D Barcode Scanner (Bluetooth)
Features
QC7556 Pocket 2D Barcode Scanner (Bluetooth)
- High performance scan rate and precision.
- Lightweight, compact form factor.
- Available in 2D, CCD and Laser engines.
- Bluetooth ver 2.1 + EDR . Supporting SPP and HID interfaces.
- Effortless BT pairing/unpairing routine.
- On-board Flash memory with one touch batch data upload.
- Supports Auto-Sense, Continuous and Manual scan modes.
- Wizard compatible with extensive settings options.
- Compatible with camera mount and stand accessories.
.jpg)
.jpg)
.jpg)
.png)
.jpg)
.jpg)
.jpg)
QC75 Series QC7556 Pocket 2D Barcode Scanner (Bluetooth)
QC7556 Pocket 2D Barcode Scanner (Bluetooth)
Description
The Q-Code 75 Bluetooth Pocket Scanner is the culmination of reliability, versatility and intuition. This elegantly compact scanner is ideal for users to carry where the business takes them. This is achieved through Bluetooth® 2.1 + EDR pairing which can support a range of up to 10m. These aspects compliment applications including Point of Sale retail or field services. The device is compatible with both 2D barcodes using our iconic Q-Engine, capable of accurately reading at a precision of 5 mil. The Q-Engine is even optimised to read from a mobile, tablet or computer screen. The pocket scanner can be charged, set up or firmware updated using our Q-Cable, delivering high performance both in data transmission and durability.
Should one need to be further away from the host device, a quick unpairing mechanism will work in tandem with 4MB of on board Flash memory collect an exhaustive amount of barcode data before returning to upload to host with a single prolonged trigger press. Alternatively the device can conveniently attach itself to a range of compatible stands for stability and hands-free barcode scanning using the built-in AutoSense mode. Additional scan modes include a Trigger mode as well as a Continuous Scan mode to suit to requirements of a given scenario.
Applications
- Point of Sale
- Price Comparison
- Ordering via Scanner
- Logistics
- Inventory Checking
- Healthcare: Admission/Discharge, Pharmacy, Patient ID.
- Ticket and Access Management
Product Specifications
|
QC7506
|
QC7516
|
QC7556
|
||
| Category: |
CCD Linear Imager
|
Laser
|
2D Imager
|
|
| Housing: |
ABS with PC
|
|||
| Performance | ||||
| Communication |
Bluetooth® Class 2(2.4GHz) Version 2.1 +EDR
|
|||
| Connected Power Consumptions |
Typical 3mA, Max 8mA
|
|||
| Data Transfer Power Consumptions |
Typical 15mA, Max 20mA
|
|||
| Interface: |
SPP / HID
|
|||
| Batch Scanning: |
YES
|
|||
| Out of Range scanning: |
YES
|
|||
| Scan rate: |
300 Scans per sec |
- |
||
| Memory: |
1MB |
4MB |
||
| 1D Symbologies: |
EAN-13,EAN-8,UPC-A,UPC-E, ISSN, ISBN, Codabar, Code 128,Code 93, ITF-6,
ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey |
|||
| 2D Symbologies: |
None
|
PDF 417, Data
Matrix(ECC200,ECC000,050, 080,100,140), QR Code |
||
| Hands-free Scanning: |
Trigger/ Auto-Sense / Continuous Modes
|
|||
| Reading Precision: |
≥ 3mil
|
≥ 5mil
|
||
| Light Source: |
610nm-640nm
|
648nm-660nm
|
Red Led 625 ±10nm
|
|
| Depth of Field: |
EAN13(13mil): 50~610mm |
EAN13(13mil):50-195mm |
||
| Symbol Contrast: |
≥ 30% Reflectance Diffreence
|
|||
| Scan Angle |
| Pitch : ±60º @ 0ºRoll and 0º Skew
|
| Pitch : 55º
|
||
|
| Roll : ±30° @ 0° Pitch and 0° Skew
|
| Roll : 360º
|
|||
|
| Skew : ±60° @ 0° Roll and 0° Pitch
|
| Skew : 55º
|
|||
| Field of View: |
-
|
Horizontal 36º ; Vertical 23º
|
||
| Mechanical/Electrcal | ||||
| Maximum Power Consumption: |
0.28W
|
0.33W
|
0.76W
|
|
| Working Hours: |
Maxell 3.7V 1100 mAh Li-ion Battery
|
|||
| Input Voltage: |
DC 5V ± 0.5V
|
|||
| Operating Current: |
85mA
|
100mA
|
230mA
|
|
| Standby Current: |
25mA
|
7mA
|
||
| Dimension: |
L 100 mm x W 46 mm x H 23 mm
|
|||
| Weight: |
150g ±10 (W/ O Cable)
|
|||
| Environmental |
|
|||
| Operating Temperature: |
-20ºC ~ +60ºC
|
|||
| Storage Temperature: |
-40ºC ~ +85ºC
|
|||
| Humidity: |
5% -95% (non-condensing)
|
|||
| Ambient Light: |
0 ~ 100,000 LUX
|
|||
| Certifications: |
FCC Class B，CE EMC Class B，RoHS
|
|||
| Accessories | ||||
| Cables: |
Micro USB 2.0 Charge 1.8M Cable
|
|||
| Certifications: |
Output: DC5V,800mA; Input: AC100~240V, 50~60Hz
|
|||
